Slides into the groove
Magnets hold the rigid shaft in a groove along the PID, locked parallel to the beam. No rods, no aiming ring.
Patent pending
Cord-Free. Battery-Free. Self-Aligned.
Power and image data run through a Smart PID dock on the X-ray unit, and the same wand squares the sensor to the beam. Nothing hangs from the head, and nothing in the mouth needs a battery.
24-second demo: Step 1 docks and aligns with no electronics; Step 2 adds power and data through the Smart PID.
The wired sensor problem
The cord between the X-ray unit and the patient’s mouth is bent dozens of times a day, rolled over by chairs and bitten. When it fails, both the manufacturer and the dentist pay.
What share of your sensor warranty returns is caused by cable damage? No public study measures it; your service records do.
How it works
The wand’s rigid shaft rides in a groove on the PID. Step 1 needs no electronics; Step 2 moves the sensor cable inside the X-ray unit.
Magnets hold the rigid shaft in a groove along the PID, locked parallel to the beam. No rods, no aiming ring.
The bend equals the groove-to-beam distance, so the sensor’s center sits on the beam axis every time.
Contacts in the PID power the sensor and carry the image. The ring turns red, yellow, then green as the wand docks.
The bitewing wand
No cable exit, strain relief, battery or radio to make it bulky.
Quadrant-specific wands follow the arch, so corners stop pressing into the tongue and floor of the mouth.
A fixed distance from the source and a known curve let imaging software flatten the image.
One dock, with a wand for each view. Slots at 12, 3, 6 and 9 o’clock cover every standard view.
Who gains
A cable-free line to sell against competitors, retrofit kits for rooms with other brands’ heads, and fewer cable warranty returns.
No $700–1,750 cable repairs, no sensor out for weeks, and fewer cone cuts and retakes.
Slide the wand into a slot and expose on green. No cord to manage and no rods or rings to assemble.
A thinner wand curved to the arch, fewer retakes, and a beam no bigger than the sensor.
Tobasco’s collimator opening matches the sensor, so the beam covers only the area being imaged, with less scatter than a wide round cone. Rectangular collimation cuts patient dose 40–92% compared with round; most offices skip it for fear of cone cuts, and a locked wand removes that fear.
For licensees
For companies that build X-ray units, sensors, or both.
Power and image data run through the PID. Nothing hangs from the head.
A replacement Smart PID or the Smart Ring fits units already in the field.
A tubehead that finds the wand builds on the same dock.
The most-reported failure point, and its warranty returns, go away.
With a replacement Smart PID or the Smart Ring, your sensor works on any brand’s head.
Thinner, curved, quadrant-specific heads that patients notice.
| Option | Change to the X-ray unit | Power and images | Best for |
|---|---|---|---|
| Replacement Smart PID | Fits the existing tubehead mount | Tubehead power, or battery pod with radio | The full Tobasco workflow on any brand’s head |
| Smart Ring | None; clamps over the existing PID | Own battery; images by radio or SD card | Heads that can’t be modified, such as leased units |
| Alignment collar | Clamps onto the existing PID | None; mechanical only | The lowest-cost first step; works with corded sensors, phosphor plates and film |
Intellectual property
| Application | Filed | Covers | Status |
|---|---|---|---|
| U.S. 19/746,539 | July 18, 2026 | Sensor wand with mechanical alignment | Docketed for examination |
| U.S. 19/783,879 | Aug. 23, 2026 | Replacement smart collar (retrofit Smart PID) | Pending |
| U.S. 19/802,445 | Sept. 9, 2026 | Smart PID powered through the tubehead | Pending |
| U.S. 64/114,903 | July 19, 2026 | Smart Ring, alignment collar, auto-tracking tubehead | Provisional |
The filed applications also cover quadrant-specific wands shaped to the arch. Claims can be reviewed under a mutual NDA.
Development status
3D-printed models of the bitewing and periapical wands are complete. Next milestone: a working bitewing wand that latches onto any existing PID.
